> >>>PSS MSB.303020 IP66 IK10 1.5MM POWDER COATED MILD STEEL ENCLOSURE GALVANISED MOUNTING PLATE GREY 300Hx300Wx200
New PSS MSB.303020 IP66 IK10 1.5MM POWDER COATED MILD STEEL ENCLOSURE GALVANISED MOUNTING PLATE GREY 300Hx300Wx200 View larger

PSS

PSS MSB.303020 IP66 IK10 1.5MM POWDER COATED MILD STEEL ENCLOSURE GALVANISED MOUNTING PLATE GREY 300Hx300Wx200

PSSMSB.303020

MSB.303020

New product

PSSMSB.303020 Compact Enclosure MSB 300x300x200mm - Single

The PSSMSB.303020 is a high-quality mild steel compact electrical enclosure designed for secure protection of control, automation, and communications equipment. Measuring 300x300x200mm, it features 1.5mm powder-coated mild steel in RAL7035 with a galvanised mounting plate and a reversible hinged door to ensure IP66 dust- and water-jet sealing, IK10 impact resistance, and quick, flexible installation.

Ideal for industrial panels, field I/O, networking and power distribution, it complies with IP66 (IEC 60529) and IK10 (IEC 62262) and offers a keyed lock option and adjustable pole clamps for versatile mounting, making it suitable for plant rooms, outdoor locations, and public-facing sites where a discreet unbranded finish is preferred.

Key Features

  • IP66 and IK10 rated enclosure for dust-tight, water-jet protection and high impact resistance
  • 1.5mm powder-coated mild steel body in RAL7035 for durability and corrosion resistance
  • Galvanised mounting plate installed and reversible door for installation flexibility
  • Standards compliance: IEC 60529 IP66 and IEC 62262 IK10; manufactured in Europe
  • Optional keyed lock, adjustable pole clamps, and IP54 vented door for thermal management
  • COLOR WHITE
  • PRODUCT TYPE ENCLOSURE
