> >>GARLAND UTPL5EHF CAT5E UTP LAN CABLE 24AWG SOLID 4P LSZH 305M GREY
GARLAND UTPL5EHF CAT5E UTP LAN CABLE 24AWG SOLID 4P LSZH 305M GREY View larger

GARLAND

GARLAND UTPL5EHF CAT5E UTP LAN CABLE 24AWG SOLID 4P LSZH 305M GREY

CBLCAT5E/305MGRY

UTPL5EHFGY305B

New product

CBLCAT5E/305MGRY Garland Cat5e UTP LAN Cable 24AWG Solid LSZH Grey - 305m Pull Box

The CBLCAT5E/305MGRY is a high-quality Category 5e UTP LAN cable designed for horizontal structured cabling and reliable 10 100 Ethernet links. Measuring approximately 5.1 mm OD, it features 24AWG solid PACW copper conductors, PE insulation, and a low smoke zero halogen LSZH outer sheath with integrated rip cord to ensure safe installation, reduced smoke and acid gas emissions, and long-term network performance.

Ideal for offices, education, healthcare, and commercial fit-outs, it complies with UL444, ANSI TIA 568 C.2, ISO IEC 11801 2, AS NZS 3080, AS CA S 008, and AS 1049, and offers 100±15 Ω characteristic impedance with verified Class D channel performance to 100 MHz, making it suitable for cable trays, risers, and general indoor routing.

Key Features

  • 24AWG solid copper 4 pair UTP rated to 100 MHz for Class D 10 100Base T performance
  • LSZH sheath for low smoke zero halogen safety in occupied spaces
  • PE insulated pairs, 5.1 mm nominal OD, 54 mm install bend radius and 111 N max pull for easy installation
  • Standards compliance UL444 ANSI TIA 568 C.2 ISO IEC 11801 2 AS NZS 3080 AS CA S 008 AS 1049
  • Supplied in grey 305 m pull box for fast structured cabling deployment
  • COLOR GREY
  • PRODUCT TYPE CAT 5e CABLE
