> >>PATRIOT OPS-24V-4A 24/27.5VDC 4.25A POWER SUPPLY & 0.6A BATTERY CHARGER 4X O/P IEC 240VAC 2U BLACK 60Hx260Wx13
New PATRIOT OPS-24V-4A 24/27.5VDC 4.25A POWER SUPPLY & 0.6A BATTERY CHARGER 4X O/P IEC 240VAC 2U BLACK 60Hx260Wx13 View larger

PATRIOT

PATRIOT OPS-24V-4A 24/27.5VDC 4.25A POWER SUPPLY & 0.6A BATTERY CHARGER 4X O/P IEC 240VAC 2U BLACK 60Hx260Wx13

PSSOPS-24V-4A

OPS-24V-4A

New product

PSSOPS-24V-4A Patriot OPS-24V-4A Open Power Supply 24-27.5VDC-4.25A-0.6A-Charger-240VAC-2U-Black-60x260x130mm

The PSSOPS-24V-4A is a high-quality 24V DC power supply and float battery charger designed for continuous-duty backup and security power applications. Measuring 60x260x130mm, it features a robust steel enclosure with efficient convection cooling and a user-adjustable 24-27.5VDC output to ensure stable, low-ripple performance at 4.25A with integrated 0.6A charging.

Ideal for access control, CCTV, alarms, and industrial controls, it complies with IEC mains input requirements and Australian RCM standards and offers mains-fail and low-battery relay outputs for remote monitoring, making it suitable for control rooms, cabinets, and mission-critical sites.

Key Features

  • 24-27.5VDC user-adjustable output at 4.25A with constant current limiting and short-circuit auto recovery for reliable load support
  • 0.6A smart charger with reverse-polarity protection supporting up to 2x12V 7Ah batteries in series for 24V standby
  • Mains fail and low battery relay contacts with status LEDs for rapid fault indication and BMS integration
  • High efficiency 86 percent with line regulation under 0.2 percent and ripple under 50mVp-p for clean DC power
  • 2U black format with optional OMNIBOX rack or floor mounting and Australian 240VAC 10A plug for quick installation
  • COLOR BLACK
  • PRODUCT TYPE POWER SUPPLY
