> >>FSH FES90M-P FEM90 SERIES HIGH SECURITY ELECTRIC STRIKE 10MM LIP MONITORED LOCK STATUS SENSOR DOOR STATUS SENSOR 35KG PRE-LOAD
High Security Electric Strike - Monitored View larger

FSH

FSH FES90M-P FEM90 SERIES HIGH SECURITY ELECTRIC STRIKE 10MM LIP MONITORED LOCK STATUS SENSOR DOOR STATUS SENSOR 35KG PRE-LOAD

FSHFES90M-P

FES90M-P

New product

High Security Electric Strike - Monitored

More details

FES90M-P FSH Motorised High Security Monitored Electric Strike - 10 mm Lip

The FSH FES90M-P is a motorised, mortise-mounted high-security electric strike with an Australian footprint and a standard 10 mm lip. It provides up to 1300 kg holding strength and releases with up to 35 kg of pre-load or side-load.

Lock Status Sensor and Door Status Sensor monitoring provide feedback on the internal locking mechanism and door latch position. The strike accepts 10-30 V DC and is fire rated for up to four hours in accordance with AS 1905.1:2015.

Key Features

  • Handles up to 35 kg of pre-load or side-load during release
  • Field-interchangeable operation supports Power to Lock or Power to Open modes
  • Sleep Mode limits current consumption to less than 15 mA at 12 V DC
  • Durability tested through 1.5 million full 35 kg pre-load cycles
  • Operating temperature range supports conditions from -20°C to +60°C
  • Certifications 4 hour fire rated
  • Colour Black/Silver
  • Holding Strength Up to 1300kg
  • Voltage Multi Voltage 10-30VDC
  • Warranty 60 Months
  • Brand FSH
  • Unit Dimensions (mm) 175.6H x 28.5W x 26D
  • Series FES90 SERIES
  • Power 10-30VDC
  • Mounting MORTISE MOUNT
  • Device Type STRIKE
  • Slimline/Standard HIGH SECURITY
  • Elec/Mech ELECTRIC
  • Backset/Lip 10MM LIP
  • Monitored MONITORED
  • Lock Status Sensor (LSS) YES
  • Door Status Sensor (DSS) YES
  • Holding Force 1300KG
  • PTO/PTL PTO/PTL FIELD INTERCHANGEABLE
  • Fire Rating 4 HOUR FIRE RATING
  • Pre-load 35KG
