> >>FSH FES110-PTO FES110 SERIES ELECTRIC DEADLOCK STRIKE SILVER MONITORED 500KG HOLDING FORCE FAIL SECURE(PTO) RECESSED MOUNT 2
FSH FES110 SERIES HIGH SECURITY ELECTRIC DEADLOCK STRIKE MONITORED FAIL SECURE (PTO) 12-24VDC View larger

FSH

FSH FES110-PTO FES110 SERIES ELECTRIC DEADLOCK STRIKE SILVER MONITORED 500KG HOLDING FORCE FAIL SECURE(PTO) RECESSED MOUNT 2

FSHFES110-PTO

FES110-PTO

New product

FSH FES110-PTO ELECTRIC DEADLOCK STRIKE MONITORED FAIL SECURE (PTO) 500KG 12-30VDC SILVER

More details

FES110-PTO FSH Monitored Fail-Secure Electric Deadlock Strike Up to 500 kg - Silver

The FSH FES110-PTO is a power-to-open fail-secure electric deadlock strike for high-security door assemblies fitted with square-bolt deadlocks. It provides up to 500 kg holding strength and operates from a multi-voltage 12-30 V DC supply.

Installed within the door frame, the strike uses Door Status and Lock Status sensors to confirm deadbolt engagement and internal strike locking. Its stainless steel faceplate and keeper provide a silver appearance, while the series is listed with an up to two-hour fire rating, with application details to be confirmed with Allegion.

Key Features

  • Power-to-open design provides fail-secure operation for controlled high-security doors
  • High holding strength supports demanding square-bolt deadlock assemblies
  • Independent sensors confirm deadbolt engagement and secure strike status
  • Multi-voltage input supports flexible integration across 12-30 V DC systems
  • Power-saving circuitry reduces current consumption after solenoid operation
  • Colour Silver
  • Warranty 24 MONTHS
  • COLOR SILVER
  • PRODUCT TYPE ELECTRIC STRIKE
  • Brand FSH
  • Unit Dimensions (mm) 58H x 32W x 306D
  • Series FES110 SERIES
  • Power 12-30VDC
  • Mounting RECESSED MOUNT
  • Device Type DEADLOCK STRIKE
  • Elec/Mech ELECTRIC
  • Monitored MONITORED
  • Holding Force 500KG
  • PTO/PTL POWER TO OPEN (FAIL SECURE)
  • Fire Rating 2 HOUR FIRE RATING
